CASE CONSTRUCTION Alpha Series - Page 269

9-SPECIFICATIONS
93100227111
LARGEVERTICALFRAMEWHEELUNIT(SV250,SV300)
ITEM
COMPONENTMEASUREMENT
SV250SV300
A
OverallOperatingHeight(FullyRaised)4176mm(164in)
B
HeighttoHingePin(FullyRaised)3302mm(130in)
CCabHeight2002mm(78.8in)
DHighestLevelBucketHeight
3038mm(120in)3169mm(125in)
E
OverallLength(NoAttachment)2990mm(117.7in)
F
OverallLength(WithstandardBucket)3708mm(146in)
GDumpAngle(FullyRaised)53.5°
H
DumpHeight(MaximumReach)2556mm(101in)
J
DumpReach(FullyRaised)744mm(29in)
K
MaximumRollback@Ground35°
L
MaximumRollback(FullyRaised)86°
MWheelBase
1322mm(52in)
P
GroundClearance(BellyPan)203mm(8in)
QAngleofDeparture23.5°
URearAxletoBumper
1034mm(40.7in)
NOTE:Measurementsarebasedonmachineswith12x16.5tiresanda1829mm(72in)LowProle(LP)bucket.
9-13
