CASE CONSTRUCTION Alpha Series - Page 277

9-SPECIFICATIONS
RCPH11WHL007FAN19
PalletFork201kg(443lb)–RatedOperatingCapacity(ROC)
Legend:
A=277mm(10.9in)B=610mm(24.0in)C=LoadCenterofGravity(CG)
Model
H=Height@maximumreachROCROCw/StandardWeightKit
SR1301330mm(52.4in)290kg(639lb)320kg(705lb)
SR1501330mm(52.4in)345kg(639lb)375kg(827lb)
SR1751480mm(52.4in)425kg(937lb)455kg(1003lb)
SV1852495mm(52.4in)440kg(970lb)470kg(1036lb)
SR2001505mm(52.4in)515kg(1135lb)545kg(1202lb)
SR2201505mm(52.4in)555kg(1224lb)625kg(1378lb)
SR2501505mm(52.4in)790kg(1742lb)860kg(1896lb)
SV2502405mm(52.4in)755kg(1664lb)835kg(1841lb)
SV3002405mm(52.4in)905kg(1995lb)985kg(2172lb)
TR270
1
1505mm(59.3in)470kg(1036lb)490kg(1080lb)
TR320
1
1545mm(52.4in)565kg(1246lb)670kg(1477lb)
TV380
1
2412mm(95.0in)756kg(1667lb)876kg(1931lb)
1
SpeciedROCfortrackmodelsis35%tippingload.
