9-SPECIFICATIONS
6310936418
LARGEVERTICALFRAMETRACKUNITS(TV380)
ITEM
COMPONENTMEASUREMENT
R
Clearancecircleradiuswithouttool1485mm(58.5in)
SClearancecircleradiuswith1981.2mm(78.0in)DF
bucket
2228mm(87.7in)
SClearancecircleradiuswith1981.2mm(78.0in)HD
bucket
2325mm(91.5in)
SClearancecircleradiuswith1981.2mm(78.0in)LPE
bucket
2438mm(96.0in)
T
Clearancecircleradiusrear1702mm(67.0in)
V
Overthetrackwidth1480mm(58.3in)
W
Overallwidth1930mm(76.0in)
Operatingweight4625kg(10196lb)
SAERatedOperatingCapacity(ROC)
35%oftippingload1209kg(2665lb)
50%oftippingload1723kg(3799lb)
Tippingload
3447kg(7599lb)
Counterweight(optional)273kg(601.9lb)
Cabsideglass(optional)21.3kg(47.0lb)
Cabglassdoor(optional)34.0kg(75.0lb)
CabLexandoor(optional)34.0kg(75.0lb)
Suspensionseat(optional)10.0kg(22.0lb)
NOTE:Allmeasurementsarebasedonmachineswitha1981.2mm(78.0in)HeavyDirt(HD)bucket.
