9-SPECIFICATIONS
6310936317
LARGEVERTICALFRAMETRACKUNITS(TV380)
LOCATIONCOMPONENTMEASUREMENT
A
OverallOperatingHeight(FullyRaised)4216mm(166.0in)
B
HeighttoHingePin(FullyRaised)3342mm(132in)
CCabHeight2043mm(80.4in)
DHighestLevelBucketHeight
3169mm(124.8in)
E
OverallLength(NoAttachment)2990mm(117.7in)
F
OverallLength(WithstandardBucket)3708mm(146.0in)
GDumpAngle(FullyRaised)53.5°
H
DumpHeight(MaximumReach)2596mm(102.2in)
J
DumpReach(FullyRaised)548mm(21.6in)
K
MaximumRollback@Ground34.2°
L
MaximumRollback(FullyRaised)86°
MTracklengthonground
1639mm(64.5in)
P
GroundClearance(BellyPan)243mm(10in)
QAngleofDeparture32°
NOTE:Allmeasurementsarebasedonmachineswitha1981.2mm(78.0in)HeavyDirt(HD)bucket.
