CASE CONSTRUCTION Alpha Series - Page 274

9-SPECIFICATIONS
6310936416
LARGERADIALFRAMETRACKUNITS(TR320)
ITEM
COMPONENTMEASUREMENT
R
Clearancecircleradiuswithouttool1466mm(57.7in)
SClearancecircleradiuswith1981.2mm(78.0in)DF
bucket
2210mm(87.0in)
SClearancecircleradiuswith1981.2mm(78.0in)HD
bucket
2307mm(90.8in)
SClearancecircleradiuswith1981.2mm(78.0in)LPE
bucket
2419mm(95.2in)
T
Clearancecircleradiusrear1702mm(67.0in)
V
Overthetrackwidth1480mm(58.3in)
W
Overallwidth1930mm(76.0in)
Operatingweight4355kg(9601lb)
SAERatedOperatingCapacity(ROC)
35%oftippingload1018kg(2244lb)
50%oftippingload1451kg(3199lb)
Tippingload
2902kg(6398lb)
Counterweight(optional)273kg(601.9lb)
Cabsideglass(optional)21.3kg(47.0lb)
Cabglassdoor(optional)34.0kg(75.0lb)
CabLexandoor(optional)34.0kg(75.0lb)
Suspensionseat(optional)10.0kg(22.0lb)
NOTE:Allmeasurementsarebasedonmachineswitha1981.2mm(78.0in)Dirt&Foundry(DF)bucket.
NOTE:ClearanceCircleRadius(R,S,T)valueswerecalculatedusinga50/50weightdistribution(centerpointof
counterrotationcenteredbetweentheaxles)andwiththebucketrestingatonground.
9-18
