9-SPECIFICATIONS
6310936315
LARGERADIALFRAMETRACKUNITS(TR320)
LOCATIONCOMPONENTMEASUREMENT
A
OverallOperatingHeight(FullyRaised)4009mm(157.8in)
B
HeighttoHingePin(FullyRaised)3215mm(127in)
CCabHeight2043mm(80.4in)
DHighestLevelBucketHeight
3038mm(119.6in)
E
OverallLength(NoAttachment)2981mm(117.4in)
F
OverallLength(WithstandardBucket)3611mm(142.2in)
GDumpAngle(FullyRaised)38.1°
H
DumpHeight(MaximumReach)2602mm(102.4in)
J
DumpReach(FullyRaised)548mm(21.6in)
K
MaximumRollback@Ground29.7°
L
MaximumRollback(FullyRaised)99.7°
MTracklengthonground
1639mm(64.5in)
P
GroundClearance(BellyPan)243mm(10in)
QAngleofDeparture32°
NOTE:Allmeasurementsarebasedonmachineswitha1981.2mm(78.0in)Dirt&Foundry(DF)bucket.
9-17
