CASE CONSTRUCTION Alpha Series - Page 272

9-SPECIFICATIONS
6310936414
MEDIUMRADIALFRAMETRACKUNITS(TR270)
ITEM
COMPONENTMEASUREMENT
R
Clearancecircleradiuswithouttool1410.0mm(55.5in)
SClearancecircleradiuswith1828.8mm(72.0in)DF
bucket
2132.0mm(83.9in)
SClearancecircleradiuswith1828.8mm(72.0in)LP
bucket
2226.0mm(87.6in)
SClearancecircleradiuswith1828.8mm(72.0in)LPE
bucket
2344.0mm(92.3in)
T
Clearancecircleradiusrear1501.0mm(59.1in)
V
Overthetrackwidth1356.0mm(53.4in)
W
Overallwidth1676.0mm(66.0in)
Operatingweight3750kg(8267lb)
SAERatedOperatingCapacity(ROC)
35%oftippingload860kg(1896lb)
50%oftippingload1225kg(2701lb)
Tippingload
2450kg(5401lb)
Counterweight(optional)63.8kg(140.7lb)
Cabsideglass(optional)21.3kg(47.0lb)
Cabglassdoor(optional)34.0kg(75.0lb)
CabLexandoor(optional)34.0kg(75.0lb)
Suspensionseat(optional)10.0kg(22.0lb)
NOTE:Allmeasurementsarebasedonmachineswitha1828.8mm(72.0in)Dirt&Foundry(DF)bucket.
NOTE:ClearanceCircleRadius(R,S,T)valueswerecalculatedusinga50/50weightdistribution(centerpointof
counterrotationcenteredbetweentheaxles)andwiththebucketrestingatonground.
9-16
