9-SPECIFICATIONS
6310936313
MEDIUMRADIALFRAMETRACKUNITS(TR270)
LOCATIONCOMPONENTMEASUREMENT
A
OverallOperatingHeight(FullyRaised)3920mm(154.3in)
B
HeighttoHingePin(FullyRaised)3124mm(123in)
CCabHeight1998mm(78.7in)
DHighestLevelBucketHeight
2950mm(116.1in)
E
OverallLength(NoAttachment)2669mm(105.1in)
F
OverallLength(WithstandardBucket)3292mm(129.6in)
GDumpAngle(FullyRaised)39.6°
H
DumpHeight(MaximumReach)2495mm(98.2in)
J
DumpReach(FullyRaised)568mm(22.3in)
K
MaximumRollback@Ground31°
L
MaximumRollback(FullyRaised)98.6°
MTracklengthonground
1419.0mm(55.9in)
P
GroundClearance(BellyPan)203mm(8in)
QAngleofDeparture32°
NOTE:Allmeasurementsarebasedonmachineswitha1828.8mm(72.0in)Dirt&Foundry(DF)bucket.
