2-SAFETYINFORMATION
3.Installtheretainingnuts.T orquethenutsto170N·m
(125lbft).
93100163310
Unlockandlowertheloaderarmformachineoperation
DANGER
Crushinghazard!
Theloaderarmisunsupportedduringsupport
strutremoval.Donotenterorexittheopera-
tor'scompartmentwithanunsupportedloader
arm.Twopersonsarerequiredduringstorage.
Onepersonshouldremoveandstorethesup-
portstrutwhiletheoperatorremainsintheop-
erator'scompartment.
Failuretocomplywillresultindeathorserious
injury.
D0021B
NOTE:Aninstructionaldecalontheinsideoftheright-
handloaderarm,justabovethesupportstrutisalsoavail-
able.Understandtheloaderarmunlockprocedurebefore
continuing.
Placingthesupportstrutinthestoragepositionrequires
asecondperson.Theoperatormustremainintheseat
duringthisprocedure.
1.Sitintheoperator'sseat,fastentheseatbelt,pullthe
restraintbardown,andstarttheengine.
2.Presstheoperatebuttontoenablethehydraulics.
3.Raisetheloaderarmuntilthesupportstrut(B)isnot
restingontheendofthecylinderbarrel(C).
RAIL14SSL0418AA11
93106854A12
4.Instructthesecondpersontoremovethesupportstrut
pin(A)andplacethesupportstrutinthestowedpo-
sitionandreinstallthesupportstrutpin(A).Whenthe
secondpersonhasclearedthearea,theoperatormay
nowlowertheloaderarm.
5.Commenceworkoperationsorparkthemachineand
stoptheengine.
93106848A13
2-21
