2-SAFETYINFORMATION

2.Pullonthehandholdsatthefrontofthemachineuntil

thecabiscompletelytiltedforward.

931074987

3.Conrmthattheredlocktubehasloweredoverthe

cabpivotlinkage.Ifithas,thecabtiltpositionisnow

secure.

RAPH12SSL0420BA8

Tiltandsecurethecabformachineoperation

1.Raisetheredlocktubeexposingthecabpivotlinkage.

2.Pushthecabbackwardintotheoperationposition.

RAPH12SSL0420BA9

2-20
