2-SAFETYINFORMATION
6.Locatetheloaderarmlockleverontheright-handside
oftheoperator’sseat.
7.Rotatethelocklevertowardtheoperator’sseat(clock-
wise)toengagethelocksupportpin(s).
8.Stoptheengine.
RAIL16SSL0012AA3
9.Pullupontheoverridecontrolknob(redcontrolknob
neartheright-handsideoftheoperator’sseat).The
loaderwillbraceagainstthelocksupportpinandkeep
theloaderarminaraisedposition.
NOTE:Onlyusetheoverridecontrolknobtolowerthe
loaderarminemergencysituationswhenenginepower
isnotavailableortoloweritontothelocksupportpinfor
servicingthemachine.
93107465A4
931074575
Tiltandlockthecabforwardformachineservice
1.Removethetwo,rearretainingnuts,locatedatthe
rearofthecab.
9310016336
2-23
