2-SAFETYINFORMATION

3.Installtheretainingnuts.T orquethenutsto170N·m

(125lbft).

93100163310

Unlockandlowertheloaderarmformachineoperation

1.Sitintheoperator'sseat,fastentheseatbelt,pullthe

restraintbardown,andstarttheengine.

2.Presstheoperatebuttontoenablethehydraulics.

3.Fullyraisetheloaderarm.

RAPH14SSL0351BA11

4.Rotatethelockleverawayfromtheseat(counter

clockwise)toretractthelockpin(s).

5.Lowertheloaderarm.

6.Commenceworkoperationsorparkthemachineand

stoptheengine.

RAIL16SSL0012AA12

2-25
