2-SAFETYINFORMATION

WARNING

Entanglementhazard!Keephandsandclothing

awayfromrotatingfanandbelts.Failuretocomply

couldresultindeathorseriousinjury.

Quantity:1

Partnumber:47739196

47739196_A18

Location:

Ontopoftheradiatorunderthehood.ModelSR130only.

RAIL16SSL0014AA19

Location:

Ontopoftheradiatorunderthehood.

RAIL16SSL0015AA20

2-35
