2-SAFETYINFORMATION

WARNING

Explosionhazard!DONOTuseetherstartinguid.

Failuretocomplycouldresultindeathorserious

injury.

Quantity:1

Partnumber:84535230

RAPH12SSL0074AA21

Location:

Underthehood,ontopoftheaircleanerbracket.Model

SR130only.

RAIL16SSL0034BA22

Location:

Underthehood,ontopoftheradiator.

RAIL16SSL0015AA23

2-36
