2-SAFETYINFORMATION

WARNING

HotSurfaceHazard.Stayclear.

Failuretocomplycouldresultindeathorserious

injury.

Quantity:1

Partnumber:47856202

47856202_A27

Location:

Ontopoftheradiator.ModelSR130only

RAIL16SSL0014AA28

Location:

Ontopoftheradiator.

RAIL16SSL0015AA29

2-38
