2-SAFETYINFORMATION

WARNING

CRUSHHAZARD

Checkattachmentforproperengagementbefore

using.Failuretocomplycouldresultindeathor

seriousinjury.

Quantity:1

Partnumber:84367568

84367568_A30

Location:

Onthebacksideofthefrontloaderarmcrosstube.

ModelsSR130andSR150only.

RAIL16SSL0011AA31

Location:

Onthebacksideofthefrontloaderarmcrosstube.

ModelsSR175,SV185,SR200,SR220,SR250,SV250,

SV300,TR270,TR320,andTV380.

RAIL15SSL0374BA32

NOTE:Readandunderstandthe“Mechanicalattachmentmountingsystem”page6-1or“Hydraulicattachment

mountingsystem”page6-4inthismanual.

2-39
