2-SAFETYINFORMATION

Model

SAERatedOperating

Capacity(ROC)

Decalpart

number

Decal/placementlocation

*SR130

590kg(1300lb)

84350672

*SR150

680kg(1500lb)

84350653

*SR175

790kg(1750lb)

84350655

*SV185

840kg(1850lb)

84350657

*SR200

905kg(2000lb)

84350658

*SR220

1000kg(2200lb)

84350660

*SR250

1135kg(2500lb)

84350661

*SV250

1135kg(2500lb)

84350661

SSL

*SV300

1360kg(3000lb)

84350664

*TR270

859kg(1894lb)

84350666

*TR320

1018kg(2244lb)

84350667

CTL

*TV380

1209kg(2665lb)

84350668

Location:

Onright-handconsole(post).

NOTE:*TheCompactTrackLoaders(CTL)areratedat35%

oftippingcapacityandtheSkidSteerLoaders(SSL)are

ratedat50%oftippingcapacity.

9310934838

9310689639
