2-SAFETYINFORMATION

NEVERmixOrganicAcidTechnology(OAT)coolant

withconventionalcoolant.Undernocircumstances

shouldyoutopoffacoolingsystemwithonlywater.

Quantity:1

Partnumber:47757330

4775733040

Location:

Ontopoftheradiator.ModelSR130only.

RAIL16SSL0014AA41

Location:

Ontopoftheradiator.

RAIL16SSL0015AA42

NOTE:See“OrganicAcidTechnology(OAT)coolant“7-14formoredetails.

2-43
