3-CONTROLSANDINSTRUMENTS
(4)HYDRAULICSYSTEMMALFUNCTION
YellowLampwillashwhenahydraulic
faultisdetected.Usethefaultcodethat
appearedintextdisplayandreferenceitin
thetroubleshootingsectionofthismanual.
(5)ELECTRONICSYSTEMMALFUNCTION
Thisyellowlampwillashandthealarmwill
sound.Usethefaultcodethatappeared
intextdisplayandreferenceitinthe
troubleshootingsectionofthismanual.
(6)SEATBELT
REDlampwillilluminatewhentherestraint
barisraised.REDlampwillalsoilluminate
whentheoperatorleavestheoperator’s
seat.
(7)
PARKBRAKELAMP:
ThisRedlampilluminatestoindicatethe
parkbrakeisengaged.
Undernormalconditionstheparkbrakewill
besetwhen:
•
Theparkbrakebuttonisactivated
(locatedontheright-handcontrollever)
•
TheOPERATEbuttonisactivated
•
Theengineisshutoff
•
Theengineisrunningandtherestraint
barisraised
•
Theoperatorleavestheseat
(8)ENGINEPREHEATINGLAMP:
Incoldclimatestartingconditions,after
turningthekeyswitchtorunposition,
thisyellowenginepre-heatinglampwill
illuminate,instructingtheoperatorthat
incomingairisbeingpreconditionedfor
smootherstarting.Theoperatormustwait
untilthelampgoesoutbeforeattemptingto
starttheengine.
