4-OPERATINGINSTRUCTIONS
Transmissiongears
NOTICE:Transmissionisde-clutchedwhentheparkingbrakeisengaged.
Thetransmissionissynchronizedinallfourgears.Youmayshifttoanygearwithoutstoppingthemachine.
Forsmoothtransitionsreleasethefootthrottlewhendownshiftingintothenextlowergear.
Choosetheappropriatetransmissiongearforthetypeofworkthemachinewillbeoperatedfor.
Shiftinggears
1.Pressandholdtheclutchcutoutbutton(1)onthegear
shiftlever(2)beforeyoushiftgears.
2.Movethegearshiftleverintothedesiredgear.
3.Releasetheclutchcutoutbutton.
Travelspeedswith19.5Lx24reartires
Gear
DirectionTravelspeedat
2330RPM
1stForwardandreverse
6.1km/h(3.8mph)
2ndForwardandreverse
11.1km/h(6.9mph)
3rdForwardandreverse
20.9km/h(13.0mph)
4thForwardandreverse
40.6km/h(25.2mph)
NOTE:Speedsaretobeusedasareferenceonly,the
speedswererecordedbasedonatotalmachineweight
of6170kg(13602lb).
Travelspeedswith17.5Lx24reartires
Gear
DirectionTravelspeedat
2330RPM
1stForwardandreverse
5.7km/h(3.5mph)
2ndForwardandreverse
10.4km/h(6.5mph)
3rdForwardandreverse
19.6km/h(12.2mph)
4thForwardandreverse
37.9km/h(23.5mph)
NOTE:Speedsaretobeusedasareferenceonly,the
speedswererecordedbasedonatotalmachineweight
of6170kg(13602lb).
RAPH12UTL0020AA1
4-12
