Case 570NXT - Disable Parking Brake

7-MAINTENANCE
Disableparkingbrake
Fordisabledmachines,disabletheparkingbrakewhenevertheparkingbrakefailstodisengage.
1.Chockthewheelstopreventmovement.
2.Removethematandoorplate.
3.Locatethesolenoidblockfortheparkingbrakeon
thetransmission.
4.Cleantheareaofdirtanddebris.
RCPH10TLB064AAF1
5.Removethetwoboltsthatsecurethesolenoidblock.
RCPH10TLB065AAF2
6.Carefullyliftupandrotatethesolenoidblock90°(1).
7.Reinstalltheboltsandtightentheboltstoatorqueof
20N·m(15lbft).
8.Attachthegreasesupplytothetting(2)andpump
approximately65pumps.
NOTICE:ExtremepressureisNOTneededtoreleasethe
parkingbrake.Overpressurizationmaydamagetheseals.
Moderateeffortisrequiredonthegreasegun.
RCPH10TLB070AAF3
9.Carefullyremovethewheelchocks,asthemachine
maynowbemoved.
NOTICE:Themachineshouldbefreetoroll.Ifthemachine
doesnotroll,theremaybeanissueintheparkingbrakeor
drivetrain.Contactyourdealer.
NOTICE:Aftergreasehasbeenusedtoreleasethepark-
ingbrakeitwillbenecessarytocleanandushtheen-
tiresystembeforeplacingthemachinebackintooperation.
Contactyourdealerforthisprocedure.
7-102
