7-MAINTENANCE

Fuellters

Replacethefuelltersaftertherst100hoursofoperationonanewmachineorifamajorcomponenthasbeen

rebuilt.Thenreplacethefuelltersevery500hoursofoperationorafteralossofenginepower.

1.Fillthefueltankbeforeproceeding.

2.Openthefueltankcapslightlytoreleasepressure.

3.Cleantheareaaroundthewaterseparatorofdirtand

debris.

4.Removethewireconnectoratthebaseofthewater

separator.

RAIL11TLB0009AA1

•

Pressonthewireclaspthatholdstheconnec-

tortothedraintoremove.

NOTE:Viewisfromunderneaththemachine.

RAIL11TLB0007AA2

RCPH10TLB031AAF3

7-70
