Case 570NXT - Air Conditioning Belt

7-MAINTENANCE
Airconditioningbelt
Inspectthetensionofanewairconditioningbeltafterthe
rst10hoursofoperationandthenevery250hoursof
operation.
1.Checkthebeltatthelocationshownwithabeltten-
siongauge.Specicationis122-149N·m(90-110
lbft).
RAIL11TLB0001AA1
2.Ifthebelttensiondoesnotmeetspecication:
A.Loosenthepivotbolt(1).
B.Loosenthelocknut(2).
C.Turntheadjustmentbolt(3)clockwiseto
tightenthebelt.Turntheadjustmentbolt
counter-clockwisebeltwillloosen.
D.Whenadjustmentiscomplete,tightenthelock
nutandpivotbolt.
RAIL11TLB0005AA2
