Case 570NXT - Front Axle Fluid Level - Four Wheel Drive

7-MAINTENANCE
Frontaxleuidlevel-Fourwheeldrive
Checktheoillevelofthefrontwheeldriveaxleevery250hoursofoperation.
NOTE:Theillustrationsmaynotmatchyourmachine.Thedrainplugs,drainposition,andthecheck/llpositionare
thesame.Youmustcheckthecenterbowlandplanetaryends.
1.Raisethewheelsabout25mm(1in)abovethesur-
facewiththeloader.
2.Rotateeachwheelsothattheoillevelplugisinthe
positionshown.
3.Lowerthewheelstothesurface.
RAIL11TLB0011AA1
4.Shutdowntheengine.
5.Slowlyremovetheplug.Oilshouldbeevenwiththe
plugorice.
6.Addoilasneeded.
7.Installtheplug.
8.Repeattheprocedurefortheotherwheel.
9.Slowlyremovetheplugfromthecenterbowl.Oil
shouldbeevenwiththeorice.
RAPH12FRK1115AA2
10.Addoilasneeded.
11.Installtheplug.
7-62
