Case 570NXT - Front Axle Fluid Level - Four Wheel Drive

7-MAINTENANCE
Frontaxleuidlevel-Fourwheeldrive
Checktheoillevelofthefrontwheeldriveaxleaftertherst20hoursofoperationwithanewmachineoraftera
componentrebuild.Thenchecktheoillevelevery250hoursofoperation.
1.Raisethewheelsabout25mm(1in)abovethesur-
facewiththeloader.
2.Rotateeachwheelsothattheoillevelplugisinthe
positionshown.
3.Lowerthewheelstothesurface.
RAIL11TLB0011AA1
4.Shutdownengine.
5.Slowlyremovetheplug.Oilshouldbeevenwiththe
plugorice.
6.Addoilasneeded.
7.Installtheplug.
8.Repeattheprocedurefortheotherwheel.
9.Slowlyremovetheplugfromthecenterbowl.Oil
shouldbeevenwiththeorice.
10.Addoilasneeded.
11.Installtheplug.
RAPH12FRK1115AA2
7-43
