Case 570NXT - Powertrain

8-SPECIFICATIONS
Powertrain
Transmission
•
ElectronicF/Rshuttlecontrol
•
OnthegoelectricFourWheelDrive(4WD)control
•
Clutchcutoutbuttonsonthetransmissiongearshiftleverandtheloadercontrollever
Manual
Fourspeed,manualgearshift,fullysynchronized
Toqueconverterratio:3.2
Speedselection:4forwardand4reverse
Gearratios:
ForwardReverse
1st5.6035.603
2nd3.4813.481
3rd1.5841.584
4th0.7930.793
Splittergearratiofordrivetofrontaxle(fourwheeldrive):1.222to1
Differentiallock
Onthego,pushbuttonactivationontheloadercontrolleverandrockerswitchneartheloadercontrolhandle
Axle,differentialandplanetaries
4WDmachines
Frontaxle
Differentialratio
2.0
Planetaryhubratio6.0
Totalreductionratio12.0
Rearaxle
Differentialratio
2.5
Planetaryhubratio6.4
Totalreductionratio16.0
Brakes
Service
•
Footpedaloperated
•
Boostedhydraulicactuated
•
Selfadjusting,maintenancefree
•
Outboardmounted
•
Wetdisc,twodiscsperside
Parking
•
Electronicconsoleswitch
NOTICE:Transmissionisdeclutchedwhentheparkingbrakeisengaged.
•
Transmissionmounted
•
SpringAppliedHydraulicReleased(SAHR)
•
Electronicforward/reverseneutralinterlock
8-2
