Case 570NXT - Coolant Reservoir (Deaeration Reservoir) Fluid Level

7-MAINTENANCE
Coolantreservoir(deaerationreservoir)uidlevel
Checkthedeaerationreservoiruidlevelevery50hours
ofoperation.
1.Toensureanaccuratelevelreading:
A.Parkthemachineonlevelground.
B.Shutdowntheengine.
C.Allowtimeforthecoolanttocompletelycool.
Coolantmustbecoldbeforeproceeding.
2.Checkthecoolantlevelonthereservoir.Thecoolant
levelshouldbebetweentheHOTMAXmark(1)and
theCOLDMINmark(2).
RAIL11TLB0006AA1
CAUTION
Burnhazard!
Hotcoolantcansprayoutifyouremovethe
llercapwhilethesystemishot.Afterthesys-
temhascooled,turnthellercaptotherst
notchandwaitforallpressuretoreleasebe-
foreproceeding.
Failuretocomplycouldresultinminorormod-
erateinjury.
C0043A
3.Addcoolantasneeded.Openthellercapbyslow-
ingturningthecapcounter-clockwiseuntilitisre-
moved.Itisnotnecessarytoremovethehosesin
ordertoremovethecap.
RCPH11TLB036BAD2
7-47
