7-MAINTENANCE

Frontaxlegreasettings

Greasethekingpinsandthefrontaxlepivotevery50hours

ofoperation,ormorefrequently,ifthemachinehasbeen

workinginwaterorextremelymuddyconditions.

•

Kingpins,two-wheeldrive-Fourtotal,twoon

eachside

RCPH10TLB063AAF1

•

Kingpins,fourwheeldrive-Fourtotal,twoon

eachside

RCPH10TLB369AAF2

•

Frontaxlepivot,remotetting-One

RCPH10TLB370AAF3

7-49
