Case 570NXT - Moving the Unit; Uniform Braking

4-OPERATINGINSTRUCTIONS
MOVINGTHEUNIT
Uniformbraking
WARNING
Lossofcontrolhazard!
Unevenbrakeforceexistsonleft-handandright-handbrakes.Toensureuniformbrakeapplication
andmaximumstoppingability,alwayslocktheservicebrakepedalstogetherwhenoperatingthema-
chinein3rdor4thgearorbeforeroadtravel.
Failuretocomplycouldresultindeathorseriousinjury.
W0146A
Usethelocklevertolocktheservicebrakestogetherfor
uniformbraking.
Engagepedallock:
1.Rotatethepedallockleverupward.
2.Slidethelockleverallthewaytotherightintotheright
brakeservicepedal.
3.Rotatethelockleverdownwardtoengagethepedal
lockposition.
Disengagepedallock:
1.Rotatethelockleverupward.
2.Slidethelockleverallthewaytotheleftcompletely
outoftherightbrakeservicepedal.
3.Rotatethelockleverdownwardbehindthepedal.
