6-WORKINGOPERATIONS
Returntodig
Afterthebucketisdumped,usethereturntodigfeaturetoplacethebucketinpositionforanotherdigcycle.Move
theloadercontrollevertotherollbackpositionandtheoatposition.Thebucketrollbackwardsuntilthebottomof
thebucketislevelandthenstops.Theloaderarmswillloweruntilthebucketreachesthegroundoryoumanually
movethecontrollevertotheneutralposition.
RCPH10TLB006FAF1
1.Bucketinoatposition
2.Bucketinrollbackposition
Adjustreturntodigbucketposition:
1.Parkthemachineonalevelsurface.
2.Applytheparkingbrake.
3.Lowertheloaderbuckettothegroundandmakesure
thebottomofthebucketisatthedesireddiggingan-
gle.
4.Shutdowntheengine.
5.Loosentheadjustingboltsforthereturntodigswitch
andmovetheswitchintheslotsothattherolleronthe
switchisrestingontheedgeofthecamontheloader
arm.
NOTE:Whenmovingtheswitchbracketforwardor
rearwardforadjustment,besurethebracketispushed
intowardthemachineastheboltsaretightened.This
willassurefullcontactoftheswitchwiththeactuating
cam.
6.Tightentheadjustingbolts.
RCPH10TLB257AAF2
6-21
