6-WORKINGOPERATIONS
Scraper:
Tiltthebuckettothescraperposition.Open
theclamtothedesireddepthofcut.Referto
thedepthindicatorinimage7.
RCPH10TLB234AAF4
Loader:
Tiltthebuckettotheloaderposition.Closethe
clamcompletely.Thebucketnowoperates
asastandardbucket.
RCPH10TLB233AAF5
Clam:
Tiltthebuckettotheclamposition.Placethe
openbucketoverthematerialtobemoved.
Closetheclamtopickupthematerial.Place
thebucketoverthenewlocationforthe
materialandopenthebuckettodumpthe
material.
RCPH10TLB236AAF6
Depthindicator-4in1bucket
Scraperpositiononly.Thedepthindicatorislocatedon
therightsideofthebucket.Thebucketopeningor,depth
ofcut,isshownonthisindicator.The4in1bucketcan
makeacutupto102mm(4in)indepth.
RCPH10TLB287AAF7
