Case 570NXT - Fuses and Relays

7-MAINTENANCE
Fusesandrelays
Themachineisequippedwithfourfuseboxlocations.Inthefrontconsole,asideconsoleboxandtwoexternal
locations(Glow-plugControlUnitandTelematicsSystem).
Frontconsole—EngineControlUnit(ECU)
fuseandrelay
1.Openthemanualstoragecompartmentlocatedinfront
ofthesteeringwheel.
2.Removethefourscrews(1).
3.Removethecompartmentinsert(2)toaccessthefuse
andrelay.
RAPH12UTL0128AA1
Fuseorrelay
reference
Designation
(1)ECUB+70Asealedrelay
(A)ECUB+20Afuse
(B)ECUB+7.5Afuse (2)
(C)LAMBDASENSORB+7.5Afuse
RAPH12UTL0126BA2
RAIL12UTL0220AA3
7-11
