3-CONTROLS/INSTRUMENTS
Consolecontrols
Handthrottle(ifequipped):
Turnthedialclockwisetoincreaseenginespeed.Turn
counter-clockwisetodecreaseenginespeed.Whenthe
footthrottleisusedandreleased,theenginewilldefault
tothespeedatwhichthehandthrottlecontrolisset.
NOTE:Ifthebrakeenabledidlefeatureisactive,thehand
throttleisdisallowedwheneitherbrakepedalispressed.
Returnthehandthrottledialtotheidlepositiontorestore
(recapture)thehandthrottle.
RAPH12UTL0021AA1
Differentiallock:
Thedifferentiallockbuttonengagesor
disengagesthedifferentiallock.Toengage
thedifferentiallock,ensurethatneitherrear
wheelisspinningfreelyandpressandhold
thebutton.Releasethebuttontodisengage
thedifferentiallock.
NOTICE:Donotusebrakesteeringwiththedifferential
lockengaged.
RAPH12UTL0021AA2
Keyswitch
Thekeyswitchhasfourpositions.
•
ACC-Turnthekeycounter-clockwisefromtheOFF
positiontoACC,togivepowertotheaccessories.
•
OFF-T oshutdowntheengine,turnthekeytotheOFF
position.Aftertheenginehasstopped,removethekey.
•
ON-TurnthekeyclockwisetotheONposition.There
willbeamomentarydelayasthesystempowersup.
Forexample,allowtwoorthreesecondswiththekey
switchatONbeforecrankingtheengineonmachines
withtheadvancedinstrumentcluster.
•
START-Turnthekeycompletelyclockwisetothe
STARTpositiontoactuatethestartermotor.After
theenginestarts,releasethekey.Thekeywillreturn
automaticallytotheONposition.
RAPH12UTL0089AA3
3-11
