3-CONTROLS/INSTRUMENTS
Raise:
Fromtheneutralposition,pulltheloader
controlleverbacktomovetheliftarmsup.
RCIL10TLB031AAF8
Rollback:
Fromtheneutralposition,movethecontrol
levertothelefttorollback(curl)thebucket.
RCIL10TLB031AAF9
Dump:
Fromtheneutralposition,movethecontrol
levertotherighttodumpthebucket.
RCIL10TLB031AAF10
Returntodig:
Afterthebucketisdumped,usethereturnto
digfeaturetoplacethebucketinpositionfor
anotherdigcycle.
Movethecontrollevertotherollbackposition
andtheoatposition.Thebucketwillroll
backwarduntilthebottomofthebucketis
levelandthenstops.Theloaderarmswill
loweruntilthebucketreachesthegroundor
youmanuallymovethecontrollevertothe
neutralposition.
RCIL10TLB031AAF11
3-10
