Workingoperations
Thismanualcontainsonlybasicinformationthatyouneedtooperatethemachine,itdoesnotincludeallpossible
conditionsforoperation.
Ifyouareanewoperator,alwaysoperateinaclearareaatadecreasedenginespeed.
Threepointhitchmodecontrol(ifequipped)
Becomefamiliarwiththeoperationofthemodecontrolswitchandhowitaffectsthefunctionalityofthethreepoint
hitchcontrollevers.
Thisisathreepositionrockerswitch.Itisrecommended
whenoperatingthethreepointhitchliftcircuitinthelaser
modethattheFlowControlRegulatorbeatthe11l/min
(3USgpm)setting.
A.LASERmode-Pushthefrontoftherockerswitchto
putthethreepointhitchliftcircuitintheLasermode.
Inthismodethelasercontrolstheliftcircuit.Useof
theliftcontrolleverwilloverridethelasermode.
B.FLOATUPmode-Puttherockerswitchthecenter
positiontoputthethreepointhitchliftcircuitinthe
FloatUpmode.Positiontheboxscraperatthedesired
position.MovetherockerswitchtoFloatUp.Move
theliftcontroltotheoatposition.Inthismodethe
threepointhitchwillnotgoanylowerbutwilloatup
asrequiredandthenreturntotheoriginalposition.
C.NORMmode-Pushtherearoftherockerswitchto
putthethreepointhitchliftcircuitintheNormalmode.
Inthismodethethreepointhitchcannotbelowered
whentheliftcontrolisintheneutralposition,orifthe
keyswitchisintheOFFposition.
