7-MAINTENANCE

Loaderhydrauliccouplerlockpins

Ifequipped,greasethelockpinsforthehydrauliccoupler

every50hoursofoperation.Use

MOLYLUBE251EP-M

grease.

NOTE:Therearetwototalttings,oneoneachside.

RCPH10TLB269AAF1

4in1bucketpivotsandgreasettings

Greasethepivotsandttingsforthe4in1bucket,if

equipped,every50hoursofoperation.Use

MOLYLUBE

251EP-Mgrease.

•

Bucketpivot-Twototal,oneoneachside

RCPH10TLB258AAF1

•

Cylinder,rodend-Twototal,oneoneachside

RCPH10TLB258AAF2

7-50
