Case 570NXT - Transmission Fluid Level

7-MAINTENANCE
Transmissionuidlevel
Checktheuidlevelofthetransmissionevery250hours
ofoperation.
1.WARNING
Rotatingparts!
Theengineisrunning.Keepclearofro-
tatingfansandbelts.
Failuretocomplycouldresultindeathor
seriousinjury.
W0275A
Startuptheengine.Theenginemustberunningat
idletoaccuratelycheckthetransmissionuidlevel.
2.Turnthedipstickhandlecounter-clockwiseandpull
outthedipstick.
RCPH11TLB027BAD1
3.Checktheuidlevelonthedipstick.Thelevelshould
bebetweenthehigh(H)markandthe(L)mark.
RCPH10TLB054AAF2
4.Shutdowntheengine.
5.Adduidasneeded.Donotllabovethehighmark.
7-66
