Case 570NXT - Grease Fittings

To Next Page

To Previous Page

7-MAINTENANCE

Greasettings

Cleanthettingsbeforegreasing.Greasethepivotpoints,pins,andttingswithTUTELAMULTI-PURPOSEEPGREASE

251H,GR-9

every10hoursofoperationoreachday.Ifyouoperatethemachineinsevereconditions,greasemore

often.

Loader

RCPH10TLB065FAM1

1.Liftarmpivot

4.Bucketcylindertrunnion

2.Liftcylinder

5.Bucketcylinder,rodend

3.Bucketlink6.Bucketpivots

1.Liftarmpivot-fourtotal,twooneachside

RCPH10TLB381AAF2

7-38
