7-MAINTENANCE

2.Liftcylinder,closedendandrodend-fourtotal,two

oneachside

RAPH12UTL0026AA3

3.Bucketlink-Twototal,oneoneachside

RCPH10TLB379AAF4

4.Bucketcylindertrunnion-Twototal,oneoneachside

RCPH10TLB380AAF5

5.Bucketcylinder,rodend-Twototal,oneoneachside

RCPH10TLB388AAF6

7-39
