Case 570NXT - Initial 20 Hours; Transmission Oil Level

7-MAINTENANCE
Initial20hours
Transmissionoillevel
WARNING
Rotatingparts!
Theengineisrunning.Keepclearofrotatingfansandbelts.
Failuretocomplycouldresultindeathorseriousinjury.
W0275A
WARNING
Unexpectedmachinemovement!
Alwaysengagetheparkingbrakebeforeexitingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W1011B
WARNING
Unexpectedmachinemovement!
Beforestartingtheengine,makesureallcontrolsareintheneutralposition.
Failuretocomplycouldresultindeathorseriousinjury.
W0311A
Checktheuidlevelofthetransmissionaftertherst20hoursofoperationonanewmachineorafteracomponent
rebuild.Thenchecktheuidlevelevery250hoursofoperation.
1.Starttheengine.Theenginemustberunningat
idlespeedtoaccuratelycheckthetransmissionuid
level.
2.Keeptheparkbrakeengaged.
3.Ensurethatthetransmissiongearshiftandthedirec-
tionalcontrolleverareintheneutralposition.
4.Raisetheloaderarmandsecureitinplacewiththe
supportstrut.
5.Liftopentheenginehood.
6.Turnthedipstickhandlecounter-clockwiseandpull
outthedipstick.
