Case 570NXT - Support Strut for Loader Lift Arm

7-MAINTENANCE
Supportstrutforloaderliftarm
WARNING
Crushinghazard!
Ifyouservicethemachinewiththeloaderliftarmsraised,alwaysusethesupportstrut.Removethe
retainingpinandplacethesupportstrutontothecylinderrod.Installtheretainingpinintothesupport
strut.Lowertheliftarmsontothesupportstrut.
Failuretocomplycouldresultindeathorseriousinjury.
W0230A
Raiseandsupportloaderliftarms:
1.Emptytheloaderbucket.
2.Raisetheloaderliftarmstothemaximumheight.
3.Shutdowntheengine.
RCPH10TLB230AAF1
4.Removetheretainingpin.
5.Lowerthesupportstrutontothecylinderrod.
6.Installtheretainingpin.
RCPH10TLB221AAF2
7.Starttheengine.
8.Slowlylowertheliftarmssothattheendofthesupport
strutrestsonthecylinder.
RCPH10TLB227AAF3
7-3
