Case 570NXT - Rear Hitch Controls

3-CONTROLS/INSTRUMENTS
Rearhitchcontrols
Threepointhitchmodecontrolswitch,if
equipped
Thisisathreepositionrockerswitch.Itisrecommended
whenoperatingthethreepointhitchliftcircuitinthelaser
modethattheFlowControlRegulatorbeatthe11l/min
(3USgpm)setting.
A.LASERmode-Pushthefrontoftherockerswitchto
putthethreepointhitchliftcircuitintheLasermode.
Inthismodethelasercontrolstheliftcircuit.Useof
theliftcontrolleverwilloverridethelasermode.
B.FLOATUPmode-Puttherockerswitchthecenter
positiontoputthethreepointhitchliftcircuitinthe
FloatUpmode.Positiontheboxscraperatthedesired
position.MovetherockerswitchtoFloatUp.Move
theliftcontroltotheoatposition.Inthismodethe
threepointhitchwillnotgoanylowerbutwilloatup
asrequiredandthenreturntotheoriginalposition.
C.NORMmode-Pushtherearoftherockerswitchto
putthethreepointhitchliftcircuitintheNormalmode.
Inthismodethethreepointhitchcannotbelowered
whentheliftcontrolisintheneutralposition,orifthe
keyswitchisintheOFFposition.
RAPH12UTL0023AA1
Threepointhitchcontrollevers,ifequipped
1.LIFT-Controlstheheightoftherearattachment.
2.PITCH-Controlsthefrontandrearpitchoftheattach-
ment.
3.TILT-Controlsthetiltontherightsideoftheattach-
ment.
4.AUX-ControlsauxiliaryfunctionsortheoptionalLeft
Tiltoftheattachment.
NOTE:IfthemachineisequippedwithOptionalLeft
TilttherstauxiliarycontrolleveristheLeftHandTilt
andthesecondauxiliarycontrolleveristheScarier.
IfthemachineisnotequippedwithOptionalLeftTilt
therstauxiliarycontrolleveristheScarier.
5.AUX-ControlsauxiliaryfunctionsortheScarier
whenthemachineisequippedwiththeoptionalLeft
Tiltfunction.
RAPH12UTL0022AA2
3-16
