Case 570NXT - Rear Axle Fluid Level; Rear Axle Breather; Rear Axle Drive Shaft

7-MAINTENANCE
Rearaxleuidlevel
Checktheoilleveloftherearaxleevery250hours.
1.Placethemachineonarmlevelsurfaceandshut
downtheengine.
2.Slowlyremovetheoilcheck/llplug.Oilshouldbe
evenwiththeplugorice.
3.Addoilasneeded.
4.Installtheplug.
RAPH12FRK0276AA1
Rearaxlebreather
Cleantherearaxlebreatherevery250hoursofoperation.Ifyouoperatethemachineinsevereconditions,cleanit
morefrequently.
1.Removedirtanddebrisfromtheareaaroundthe
breatherandcleanwithsolvent.
NOTE:Imageisfromtherearofthemachinelookingto-
wardsthefrontofthemachine.
2.
CAUTION
Eyeinjuryhazard!
Wearprotectivegoggleswhenusing
compressedair.
Failuretocomplycouldresultinminoror
moderateinjury.
C0035A
Blowdrytheareawithcompressedair.
3.Spinthetopcaptoensuethatitisfreetoturn.
RAPH12UTL0123AA1
Rearaxledriveshaft
Greasetherearaxledriveshaftevery250hoursofopera-
tion.UseTUTELAMULTI-PURPOSEEPGREASE251H,GR-9.
RCPH10TLB061AAF1
