3-CONTROLS/INSTRUMENTS

Drivinglights

Presstheemblemendtoactivatethedriving

lights.Presstheothersidetoturnoffthe

drivinglights.

RAPH12UTL0089AA4

Frontworklights

Presstheemblemendoncetoactivatethe

frontworklightsonly.Presstheoppositeend

toturnoffthefrontworklights.

RAPH12UTL0089AA5

FourWheelDrive(4WD),ifequipped

Whenthefrontdriveaxleisengaged,operatethemachineonlyin1stor2ndgear.Disengagethefrontdriveaxle

beforeoperatingonthehardsurfaceorin3rdor4thgear.

Presstheemblemendoftherockerswitch

toengagethefrontdriveaxle.Theemblem

illuminates.Presstheoppositeendto

disengage.Theemblemnolongerilluminates.

RAPH12UTL0089AA6

3-12
