6-WORKINGOPERATIONS
Removeanattachment:
1.Withtheattachmentrestingontheground,pressand
holdtheleftemblemofrockerswitchtoretract
thecouplerlockpins.
2.Raisetheattachmentamaximumof25.4-50.8mm
(1-2in)offthegroundandslowlyrotatethetopofthe
attachmentoutwarduntilthelockpinsareclearofthe
attachmentmountingbores.
3.Releasetherockerswitch.
RAPH12UTL0022AA7
4.Carefullylowertheattachmenttothegroundwhilero-
tatingthetopofthecoupleroutward.
5.Whentheuppercouplermountingpinsarefree,back
awayfromtheattachment.
