(D)AUXcontrollever(lefttiltoptional)
NOTE:Ifthemachineisequippedwithlefttiltoptional,the
rstauxiliarycontrolleveristhelefthandtiltandthesec-
ondauxiliarycontrolleveristheScarier.Ifthemachine
isnotequippedwithoptionallefttilttherstauxiliarycon-
trolleveristheScarier.
TheTiltcontrolleverisathreepositionlever.The
optionalfunctionalityoftheleveristolowerorraisethe
lefthandsideoftheattachment.
1.TILTlower—Pushtheleverforward,awayfromthe
operator,tolowertheleftsideoftheattachmentor
lowersthescarier.
2.HOLD—Thecentralormidpositionisneutralorhold.
3.TILTraise—Pulltheleverbacktoraisetheleftside
oftheattachmentorraisesthescarier.
RAPH12UTL0022AA11
RAIL12UTL0178BA12
RAIL12UTL0179BA13
