7-MAINTENANCE

3.Refertothedecalontheinteriorsideofthepanelcover

forfuse,relay,and/ordiodefunctions.

RAPH12UTL0121AA8

Glow-plugControlUnit(GCU)fuse

1.Raisetheloaderarmandengagethesafetysupport.

2.Lifttheenginehood.

3.Locatethe60AfuseboxfortheGCUontherighthand

sideoftheengine.

RAPH12UTL0056AA9

4.Removetherubberfusecover(2)toviewthefuse(1)

RAPH12UTL0097AA10

7-13
