1-GENERALINFORMATION
Rightsideconsole
RAPH12UTL0110GA4
1.Loadercontrolwithclutchcutoutanddifferentialpushbuttons
2.Electronichandthrottle(ifequipped)
3.Vandallock-upcover(optionalequipmentoncanopymachinesonly)
4.Consolecontrolsandswitches
5.Threepointhitchmodecontrolswitch
6.Threepointhitchcontrollevers
Frontconsole
1.Manualstoragecompartment
2.Transmissioncontrolleverwithclutchcutoutpush
button
3.Footthrottle
4.Leftandrightbrakepedalswithlockinglever
5.Directionalcontrollever:Forward-Neutral-Reverse
(FNR)
RAPH12UTL0013AA5
