7.Placeapieceofhoseontotheradiatordrainvalve
anddrainintoasuitablecontainer.
RCPH10TLB040AAF3
8.CAUTION
Burnhazard!
Hotcoolantcansprayoutifyouremove
thellercapwhilethesystemishot.After
thesystemhascooled,turnthellercap
totherstnotchandwaitforallpressure
toreleasebeforeproceeding.
Failuretocomplycouldresultinminoror
moderateinjury.
C0043A
Openthellercaponthedeaerationreservoir.
Openthellercapbyslowingturningthecap
counter-clockwiseuntilitisremoved.Itisnotnec-
essarytoremovethehosesinordertoremovethe
cap.
RCPH11TLB036BAD4
9.Usea13mmtooltoremovethetwoboltsthatsecure
thecoolers.
10.Swingthecoolersoutandcleanofdirtanddebris.
11.Checkthehoses,elbows,andsystemcomponents
forwearordamage.
12.Aftercleaning,swingthecoolersbackinandreplace
thetwobolts.
RCPH10TLB041AAF5
13.Afterallthecoolanthasbeendrained,closethedrain
valve.Donotdetachthedrainhose.
14.AddCASECONSTRUCTIONradiatorushandfol-
lowthedirectionsoncontainer.
15.Aftertheradiatorushhasbeenused,closethera-
diatordrainvalveanddetachthedrainhose.
16.AddCNHXHDPREMIXoramixtureof50%ethylene
glycoland50%waterintothedeaerationreservoir
untilthelevelreachesbetweentheCOLDMINmark
andtheHOTMAXmarkonthetank.
17.Installthellercap.
18.Startuptheengine.
