Case 570NXT - Page 249

To Next Page

To Previous Page

7-MAINTENANCE

Replacethebulbinaturnsignal/asheroratail/stoplamp:

1.Removethetwoscrewsthatsecurethelens(1)to

theROPScanopyandremovethelens.

2.Replacethebulb(2)inthesocket.

NOTICE:Donotovertightenthescrewsotherwiseyoumay

crackthelens.

3.ReinstallthelensandsecuretotheROPScanopy.

RCPH10TLB001BAF4

7-107
